TCA Tech provides excellent electronics PCB manufacturing services with focus on quality compliance and cost effectiveness. From Prototype PCB to large volume manufacturing, TCA Tech aims to meet every client technology needs and comply with quality requirements and related standards certification.

TCA Technology can make multi-layer PCB up to 20L, including Rigid PCB, Flexible PCB, Rigid Flex PCB, Aluminum PCB, High Frequency PCB, HDI PCB ect.

Online PCB Fabrication Technology Including:

• Fast PCB prototyping services
• Non Through Plating Holes PCB
• Double Side PTH PCB
• Multi-layer PCB up to 20L
• Rogers,Taconic, Nelco&Arlon PCB manufacturing

TCA Tech panelizes different shape PCB designs in standard size ratio to minimize PCB manufacturing cost. TCA Tech helped numerous clients in the past, based on extensive design and manufacturing experience, in debugging common issues of their design and enabling them for mass production.

We won a lot of PCB projects from Aerospace, Marine, military, industry, Automotive and security due to our technologies and services.

Items	Rigid PCB	Flex PCB	Rigid-Flex PCB	Aluminum/Copper PCB
Layer Counts	1-20L	1-6L	2-10L (36/10)	1-2L
Maximum Size	1100×650mm	610mm×1650mm	610mm×1650mm	1190×600mm
Material	CME1、CME3、FR-4, High TG FR4 , Halogen-free FR4 , Polyimide ,aluminium 、Ceramic(96% Alumina) Teflon、PTFE（F4B，F4BK）, Rogers（4003，4350,5880） Taconic（TLX-8，TLX-9）, Arlon（35N，85N） etc.
Material Mixed Laminate	4 layers — 10 layers ( FR4+Ro4350 , FR4+Aluminium , FR4+ FPC)
Board Thickness	0.1mm–10.00mm
Copper Thickness	0.5-6OZ, Pilot run: 12OZ
Minimum Line / Space	0.075m(3mil)
Board Outline Tolerance	±0.1mm
Trace width Tolerance	10%
Minimum Drilling Hole	Mechanical 0.1mm, Laser hole 0.075mm
Hole Position/hole Tolerance	±0.05mm PTH:±0.076MM NPTH:±0.05mm
Mini Solder Mask Bridge	0.05mm
Impedance Control Tolerance	±8%
Surface Finishing	HASL, Lead free HASL, Immersion gold, Immersion tin, Immersion Silver,Plated gold , OSP, Carbon ink, ENEPIG, Gold Finger
Special Process	Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control.
1-2L Lead-time	Sample Expedited 24 hours and 48 hours, Normal2-5 days, Mass production 5-7days
4- 8L Lead-time	Sample Expedited 48 hours 72 hours, Normal 5-7days,Mass production 7-10 days
10-18L Lead-time	10-15 days,Special circumstances based on the actual PCB design
More than 20L Lead-time	15-20 days ,Special circumstances based on the actual PCB design
Acceptable File Format	ALL Gerber Files、POWERPCB、PROTEL、PADS2000、CAD、AUTOCAD、ORCAD、P-CAD、CAM-350、CAM2000 etc.

TCA Tech PCBs manufacturing Capabilities

Being a top PCB manufacturer in China, TCA tech aims to meet customer’s needs of PCB manufacturing using various materials and technologies, unswervingly comply with customer quality and certification standards.

TCA Tech targets customer’s aim of quality and delivery of efficient PCBs, as well as ensuring fast delivery on competitive cost.

PCB Board Production Capacity

• Layers：1-58L;
• Material：CME1、CME3、FR-4, High TG FR4 , Halogen-free FR4 , Polyimide ,aluminium 、Ceramic(96% Alumina) Teflon、PTFE（F4B，F4BK）, Rogers（4003，4350,5880） Taconic（TLX-8，TLX-9）, Arlon（35N，85N） etc.
• Material Mixed Laminate：4 layers -10 layers ( FR4+Ro4350 , FR4+Aluminium , FR4+ FPC)

Relevant PCB manufacturing knowledge

Being a top PCB manufacturer in China, TCA tech aims to meet customer’s needs of PCB manufacturing using various materials and technologies, unswervingly comply with customer quality and certification standards.

TCA Tech targets customer’s aim of quality and delivery of efficient PCBs, as well as ensuring fast delivery on competitive cost.

What is PCB?

PCB is the abbreviation of Printed Circuit Board and refers to a substrate for assembling electronics components and interconnecting them using copper wires on fiber glass material. PCB thus forms interconnection of various electronics components as per predefined circuit. PCB plays the role of relay transmission and thus called “the mother of electronics products”. Multiple PCBs can be connected to form complex electronics system and thus necessary for all electronics devices.

This page provided details of PCB manufacturing and TCA Tech capabilities of PCB manufacturing.  TCA Tech can provide PCB manufacturing and assembly for SMT, rigid, flex and multi-layered PCBs. Please contact for getting quote through given email address.
